14 Slots Media Converter Chassis

Media Converter Chassis, 19” 2U Rackmount

Features

AC 220V Power supply, adapted to a variety of working environments.
14 insert bad, can be directly inserted into the desktop optical fiber transceiver, convenient for users to choose.
Support multiple modules to work at the same time, and each module supports hot interpolation function.
Modular power supply, stable power supply and long life.

Application

The TX14SMCC is 14-slot Media Converter Chassis is designed for seamless network management. This standard chassis fits easily into machine room racks and features a modular power supply for convenient maintenance and excellent shielding. With the capacity to hold up to 14 different optical fiber transceiver modules, each module operates independently or cooperatively for network diagnosis. Boasting hot-plugging support, dual power supplies for uninterrupted operation, and AC 220V compatibility, the TX14SMCC is perfect for telecoms, cable TV, and high-performance network security systems. Experience centralized, intelligent management with over 50,000 hours of fault-free operation.

Parameter Table

Model	TX14SMCC	Number of Slots	14
Power Consumption	Full-load<68W	Material	Iron
Fan numbers	0	Dimensions (HxWxD)	90x485x245mm
MTBF (hrs)	>50,000Hrs	Output Power	≤65W
Weight	5.2kg	Input Power	100~240V AC
Operating Temperature	0°C to 50°C	Storage Temperature	-40°C to 85°C
Relative Humidity	5%~95% (Non-condensation)
