1. PAM4 modulation technology
2. EML + PIN, MTP/MPO-12 connector
3. Low power consumption < 10W
4. 8x 53.125Gb/s 400GAUI-8 electrical interface
5. Parallel 4 optical lanes, support 4x 100G breakout to QSFP28 100G-DR, 100G-FR, and 100G-LR
6. Applied in 400G Ethernet, Infiniband interconnects, data centers, high-performance computing networks
1. 400G Ethernet IEEE 802.3bs 400GBASE-DR4
2. Data Center Interconnect
| Form Factor | QSFP-DD | Interface Type | DR4 |
| Max Data Rate | 425Gbps (4×106.25Gb/s) | Wavelength | 1310nm |
| Connector | MTP/MPO-12 | Cable Type | SMF |
| Max Cable Distance | 500m | Modulation | PAM4 |
| TX Power | -2.9~4.0dBm | Receiver Sensitivity | < -5.9dBm |
| Transmitter Type | EML | Receiver Type | PIN |
| Power Consumption | < 10W | Temperature Range | 0 to 70°C (32 to 158°F) |
| DDM/DOM | Supported | Forward Error Correction (FEC) | Host FEC Supported |
| Protocols | QSFP-DD MSA, IEEE 802.3bs | Warranty | 1 Years |
